Maxus eDeliver 3 Medium Van L1 118kW H1 Van 50.2kWh Auto

Insurance Group 1:

N

Insurance Group 2:

N

Chassis Engine Number:

N

Vin/Frame No.:

N

Coin Series:

N

Coin Description:

N

Standard manufacturers warranty - Years:

5

Standard manufacturers warranty - Mileage:

60000

Manufacturers Paintwork Guarantee - Years:

3

Man Corrosion Perforation Guarantee - Years:

10

Exhaust System:

N

Front Brakes:

VENTILATED DISCS

Rear Brakes:

VENTILATED DISCS

Hand Brake:

N

Battery Volts:

0

Battery AH:

0

Alternator Amps:

0

Front Suspension:

MCPHERSON STRUT

Rear Suspension:

LEAF SPRINGS

Steering:

PAS

Clutch:

N

Any aspect of the vehicles safety cause concern?:

Coin Wheelbase Description Code:

N

Coin Wheelbase Name Code:

N

Coin Gross Vehicle Weight Code:

N

Coin Power Output Code:

N

Special Edition:

Special Order:

Based On ID:

0

Running Cost League Headings:

MEDIUM

Ghost model for valuation purposes:

Service Interval Mileage:

18000

Service Interval Frequency - Months:

24

NCAP Adult Occupant Protection %:

0

NCAP Child Occupant Protection %:

0

NCAP Overall Rating - Effective February 09:

0

NCAP Pedestrian Protection %:

0

NCAP Safety Assist %:

0

Badge Engine CC:

0

Badge Power:

160

Vehicle Homologation Class:

N1

Generation Mark:

1

NCAP Overall Rating - LCV:

N

Relative Height:

H1

Relative Length:

L1

Minimum Kerbweight:

1615

Gross Vehicle Weight:

2660

Fuel Tank Capacity (Litres):

Max. Towing Weight - Braked:

1030

Max. Towing Weight - Unbraked:

750

Payload:

1045

Load Space Volume:

4.8

Boot Capacity Saloons:

Luggage Capacity - 2nd Row Seats Up:

Luggage Capacity (Seats Down):

Luggage Capacity - 3rd Row Seats Up:

Luggage Capacity - 3rd Row Seats Down:

Luggage Capacity - 2nd Row Seats Removed:

Luggage Capacity - 3rd Row Seats Removed:

No. of Seats:

2

Max. Roof Load:

75

Luggage Capacity (Seats Up):

0

Plated Front Axle:

1250

Plated 2nd Axle:

1460

Gross Train Weight:

2750

Length:

4555

Width (excluding mirrors):

1780

Wheelbase:

2910

Height:

1900

Height (including roof rails):

0

Load Length:

2180

Load Width:

1665

Load Height:

1330

Turning Circle - Kerb to Kerb:

11.74

Front Overhang:

780

Rear Overhang:

865

Side Load Door Width:

710

Side Load Door Height:

1270

Upper Rear Door Width:

0

Load Space Width Between Wheel Arches:

1220

EC:

EC Urban:

EC Extra Urban:

EC Combined:

0 to 62:

8.9

Top Speed:

75

BHP:

160

PS:

1

0 to 60:

Engine Power KW:

118

Engine Torque LBS.FT:

166

Engine Torque NM:

225

Engine Torque MKG:

22.9

Bore:

Stroke:

CC:

1

Cylinders:

0

Cylinder Layout:

N

Number of Valves:

0

Valve gear:

N

Fuel Type:

ELECTRIC

Catalytic Convertor:

Engine Layout:

FRONT TRANSVERSE

Compression Ratio:

N

Gears:

1 SPEED

Engine Make:

N

Fuel Delivery:

N

Cooling System:

N

Automatic Transmission:

1

Manual Transmission:

Engine Codes:

N

Tyre Size Front:

185/65 R15

Tyre Size Rear:

185/65 R15

Wheel Type:

15" STEEL

Wheel Style:

N

Tyre Make:

N

Plated 3rd Axle:

0

Plated 4th Axle:

0

Alloys?:

Automatic Clutch:

1

CO2:

0

Standard Euro Emissions:

N

Noise Level dB(A):

CO:

NOx:

HC+NOx:

Particles:

HC:

Battery Capacity in kWh:

50.2

Battery Charging Scenario 1 - Power Supply - kW:

11

Battery Charging Scenario 1 - Percentage Change:

5-100

Battery Charging Scenario 1 - Charge Time (Mins):

336

Battery Charging Scenario 2 - Power Supply - kW:

57

Battery Charging Scenario 2 - Percentage Change:

5-80

Battery Charging Scenario 2 - Charge Time (Mins):

45

Battery Charging Scenario 3 - Power Supply - kW:

Battery Charging Scenario 3 - Percentage Change:

N

Battery Charging Scenario 3 - Charge Time (Mins):

0

Battery Charging Scenario 4 - Power Supply - kW:

Battery Charging Scenario 4 - Charge Time (Mins):

0

Battery Leased:

Battery Type:

Lithium-ion

Standard manufacturers Battery warranty - Mileage:

100000

Standard manufacturers Battery warranty - Years:

8

WLTP - EC (kWh/100km) - Comb:

23.7

Coupler/Connector Type:

Type 2

WLTP - Pure Electric Range (km) - City:

322

WLTP - Pure Electric Range (km) - Comb:

227

Battery Charging Scenario 4 - Percentage Change:

N

WLTP - EC (miles/kWh) - Comb:

2.6

WLTP - Pure Electric Range (miles) - City:

200

WLTP - Pure Electric Range (miles) - Comb:

141

Battery Capacity % guaranteed under warranty:

70

Charging Port Location:

Front

Usable Battery Capacity:

46.21

Maximum Charging Rate - kW:

57

Emissions Test Cycle:

WLTP

RDE Certification Level:

N

Cruise control:

Lane keep assist:

Lane departure warning system:

Electric power steering:

Reverse camera:

Driver monitor system:

Central locking:

Immobiliser:

Speed sensitive automatic lock:

Intelligent anti theft security system:

2 Remote control keys:

Driver's airbag:

Front passenger airbag:

Reversing image:

Reversing radar:

Driver seatbelt lock reminder:

Electric front windows:

Front fog lights:

Halogen headlights:

Automatic headlights:

Daytime running lights:

Manual adjustment headlights:

Halogen taillamps:

Full steel bulkhead:

Cargo area partition without glass:

Leather steering wheel:

Cloth upholstery:

Height adjustable steering wheel:

Rake adjustable steering wheel:

Storage under front seats:

Front cup holders:

Multi function steering wheel:

12V socket:

Storage compartments in front doors:

Stainless steel cargo area floor:

Handbrake:

Steering wheel with audio controls:

4 cargo area floor strapping rings:

Electronic knob:

Heated seats:

4 direction adjustable driver's seat (Front/back, seat up/down):

Speed limiter:

2 speakers:

USB port and mini jack port for driver and passenger:

MP5+DAB radio:

Bluetooth:

Apple CarPlay and Android Auto:

Automatic air conditioning:

Rear parking sensor:

Speed limit information function:

Emergency brake assist:

Electronic Stability Control (ESC):

Front and rear ventilated discs:

Automatic emergency braking system:

Hill hold control:

Leaf spring rear suspension:

Front McPherson independent suspension:

TPMS (Tyre pressure monitoring system):

eCall:

Automatic power failure collision:

2 Driver mode:

3 energy recovery modes:

Mobile phone mapping:

Infotainment system:

10.25" Touch screen:

Body colour front bumper:

Nature colour rear bumper:

Roof rack mounting points:

Single slide door:

60/40 split doors:

Rear double opening tailgate (blind window) with 180 degree hinges:

Side wall full coverage:

Storage space under bench seat:

Electric heated exterior mirror:

Ternary polymer lithium battery:

Battery thermal management - Liquid cooling and Liquid heating:

PTO - Interface:

LED cargo light:

LED front reading light:

11kW AC charger:

6m Charging cable (Model 3, 16A 11KW):

6m Charging cable (EVSE cable-3 pin 10A) 2.2KW:

V2L exterior function without discharge cable:

Removable front tow hook:
